| Display screen |
6.1” x 3.5” (156mm x 90mm) Color TFT Touch Screen |
| Audio input |
18 input: |
| |
12-way XLR/TRS composite interface MIC/LINE, 2-way stereo AES (XLR interface), 1-channel stereo USB disk or Bluetooth playback |
| Audio output |
14 outputs: |
| |
2 main outputs (XLR interface) |
| |
2-way auxiliary output AUX1, AUX2 (1/4” TRS stereo interface) |
| |
4-way auxiliary output SUB1 to SUB4 (XLR interface) |
| |
One stereo AES output (XLR interface) |
| |
One stereo USB disk recording |
| |
One stereo monitor (1/4” TRS stereo interface, 16Ω minimum impedance headphones) |
| Input channel processing |
4-band parametric equalization, Hi/Low shelving type response setting, variable frequency 24dB/octave, high-pass and low-pass filter, noise gate, limiter |
| Output channel processing |
Main output Main-L/R and AUX1~2, SUB1~SUB4 auxiliary output: 1/3 octave graphic equalizer, variable frequency point high pass and low pass filter, four sections of variable frequency point notch filter, limit The amplitude, delay. |
| recording function |
Stereo two-channel recording, in the main output Main-L/R and AUX1/AUX2, SUB1/SUB2, SUB3/SUB4 auxiliary output select a set as recording source. |
| Grouping |
6 DCA groups (with mute), 3 mute groups |
| effect |
2 professional effects: Reverb, Echo, Chorus, Pitch-shift, Flanger, Stereo Delay |
| |
60 factory presets, 50 user presets, 1 tone correction (can be assigned to any mono input channel) |
| Default |
Mixer presets: Factory and user presets include storing all mixer parameters from the internal and USB flash drives or uploading them to the console. |
| |
Channel presets: User channel presets can be stored internally or uploaded to a USB flash drive or uploaded to the console. |
| External control |
The IOS digital mixing console APP software on the iPad accesses and controls all parameters of the console via a Wi-Fi hotspot. |
| Wi-Fi |
USB Wi-Fi adapter included |
| Bluetooth Bluetooth |
USB Bluetooth adapter included |
| Size (height and width depth) |
89 mm x 360 mm x 297 mm |
| weight |
2.98 kg |
| Operating voltage requirements |
100Vac to 240Vac, 50 - 60 Hz |
| Sampling frequency |
48kHz |
| Signal delay |
Less than 1.6 milliseconds, from any input to output |
| Total harmonic distortion |
<0.005%, +4 dBu, 20 Hz - 20 kHz, 0 gain compensation or attenuation, from any input to output |
| Frequency response |
20 Hz - 20 kHz +/-0.5 dB from any input to output |
| Dynamic Range |
105dB |
| Equivalent input noise |
-128dBu |
| Residual output noise |
-86dBu |
| Crosstalk |
-80dB |
| Signal to noise ratio |
-94dB |
| Maximum input level |
+16dB (microphone input), +22dB (line input) |
| Phantom power supply |
+48V, individual switch settings for each channel |
| Include attachments |
USB WIFI adapter, USB Bluetooth adapter, power cord |
